6kVA|10kWh SOLAR INVERTER (pay on Installments)

The Ignite 6kVA|10kWh is a hybrid power solution. It integrates power supply, backup power, and management. It is
widely used in off-grid and unreliable grid areas and provides reliable and stable backup power for residences, apartments,
shops, and emergency scenarios.
Ignite 6kVA|10kWh features a high-density design, small size, lightweight, and IP65 protection level. It can be installed indoors,
or outdoors

TECHNICAL SPECIFICATIONS:

• Basic Parameter
  Dimensions（W x H x D） 690mm x 1480mm x 165mm@15kWh
  Weight • 32kg per power module，100kg per battery module
  • 166kg@15kWh
  Installation Mode Indoor, outdoor
  Protection Level IP65
• AC Input
  Input Voltage Single-phase 90~300 VAC
  Input Current Max: 30A
  Frequency 50 Hz/60Hz
  Surge Protection 3kVA/5kVA，8/20μs
• PV Input
  Start-up Voltage 100VDC
  Rated Input Voltage 340V
  MPPT Voltage 90~435V DC
  Max. Input Current 2 x 15A
  Recommended PV Power 5000Wp
  Numbers of PV Strings 2 strings
  Number of MPPT Routes 1 route
  Max. Input Current per Strings 15A
  Surge Protection 3kVA/5kVA，8/20μs
• AC Output (off-grid)
  Output Voltage Single-phase 200–230 VAC
  Max. Output Current 25.8A
  Output Power 6kVA，5kW
  Power Factor 0.8
  THD Harmonics ≤3% @ rated output
  Surge Protection 3kVA/5kVA，8/20μs
• Battery Parameter
  Voltage 350-435VDC
  Rated Capacity 5kWh per module
  Actual Capacity 5KWh (100%DOD) per module
  Max. Capacity
  Stand-alone scenario: support max.6 pcs batteries, 5kW@max.30kWh
  Parallel scenario: support max.3 power modules in parallel, each power
  module supports max. 3 pcs batteries, max.3*(5kw@max.15kWh)
  Max. Output Power 2.5kW per module
  Cycle Life 6000 cycles @ 25℃, 80%DOD
• Panel
  12x 400W PV Panel

Included in the price:

• Preliminary Energy Audit
• Subsidy Discount

Warranty:

• 5 Years
